C/B 10A 50VDC/250VAC

Code: 8205752
Stock Status: In Stock
  • The SF2258 is a robust, versatile panel mount circuit breaker suitable for both AC and DC circuits, with a 10-amp rating.

    **Tripping Times:**

  • % of Rating
  • Time to Trip

  • -------------
  • ------------------

  • 100%
  • Indefinite

  • 150%
  • <1 Hour

  • 200%
  • 4.0 - 30.0s

  • 300%
  • 2.5 - 11.0s

  • 400%
  • 1.6 - 7.0s

  • 500%
  • 0.8 - 2.5s

  • 600%
  • 0.6 - 1.7s


  • **Typical Derating Factors:**

    The rating will adjust by the approximate percentage indicated in the table below:

  • TEMP °C
  • 10-25A
  • 3-5A

  • ---------
  • --------
  • -------

  • 60
  • 50%

  • 50
  • 60%

  • 40
  • 72%
  • 45%

  • 30
  • 85%
  • 70%

  • 25
  • 100%
  • 100%

  • 20
  • 110%
  • 120%

  • 10
  • 125%
  • 145%


$9.96

EACH
